P10 Outdoor Fixel LED Display Unit

• Cabinet
• Pixel Configuration1R1G1B
• Pixel Pitch CategoryP10
• Pixel Pitch10mm
• Modules ComponentAluminium Shell
• Dimensions (W × H × D)120*960*127
• Resolution12*96
• Area0.1152
• Weight5KG/PCS
• Pixel Density1152/cabinet
• Lamp Board HousingYES
• Cabinet MaterialAluminium Profile
• Maintenance MethodBack Maitenance
• Cabinet Flatness0.8mm
• Protection LevelIP67(F)/IP66(R)

• Display
• White Balance Brightness6000
• Color Temperature3000K-10000K
• Viewing Angle160°（H）/80°（V）
• Contrast Ratio8000:1
• Color Uniformity≧0.95
• Brightness Uniformity≧0.95

• Processing Performance
• Driving MethodConstant Current
• Frame Frequency50/60HZ
• Refresh Rate3840
• Grey Level14bit
• Display Color

  DCI-P3

  ＞85%

• Power
• Power Supply110-220
• Max. Consumption580
• Average Consumption200

• Working Environment
• Working Temperature-40~+60℃
• Working Humidity10% to 95% RH (non-condensing)
• Storage Humidity10% to 95% RH (non-condensing)
• Storage Temperature-40~+80℃

• General
• Gross Weight10
• Package Dimensions (W × H × D)1040mm*160mm*200mm
• Lifespan100000 Hours

Datasheet: P10 Outdoor Fixel LED Display Unit
